|Place of Origin:||China|
|Model Number:||Dia 13.5mm - 40mm|
|Minimum Order Quantity:||50000 pcs|
|Packaging Details:||Packed in strong carton,suitable for long distance ocean transportation.|
|Delivery Time:||30 days|
|Payment Terms:||L/C, T/T, Western Union|
|Supply Ability:||300 millions pcs per year|
|Material:||Aluminum||Color Of Printing:||Up To 6 Colors|
|Name:||Aluminum Soft Tube||Diameter:||13.5mm~40mm|
|Cap Type:||Screw Cap,flip Top Cap,customized Cap,etc||Factory Direct:||YES|
empty toothpaste tubes,
custom tube packaging
Toothpaste Tube For Dental Care Aluminum Collapsible Tubes With Long Nozzle / Small Screw Cap
Hubei Xinji Pharmaceutical Packaging Co.,Ltd located in China’s central city of Wuhan city circle, established in 1981 with nearly 40 years experience in aluminum collapsible tube manufacturing.
We are the 3rd largest manufacturer of aluminum collapsible tube industry. Our tube is made of good quality aluminum material with advanced printing machine in a GMP workshop. These tubes are widely used for pharmaceutical ointment/cream packing, and also cosmetic packing, such as hair dying cream, hair bleaching cream, etc.
|British Standard of Aluminum Collapsible Tube BS2006-1984|
|Sheet3 Size Standard|
|Tolerance of Diameter||
|Tolerance of Length||
|Tube Wall Thickness||Shoulder Thickness|
|Max||Min||Max||Min||Shoulder Angle Standard|
|60||0.11||0.07||0.5||0.3||90℃ or 120℃ or 126℃|
|13.5||75||60 or 70||0.11||0.07||0.5||0.3||90℃ or 120℃ or 126℃|
|16||100||80||0.12||0.08||0.65||0.35||120℃ or 126℃|
|19||110||95||0.13||0.1||0.65||0.35||120℃ or 126℃|
|22||130||95 or 115||0.14||0.1||0.65||0.35|
|25||150||95 or 115||0.14||0.1||0.7||0.4||No Standard|
|45||±0.25||200||115 or 135||0.18||0.12||0.9||0.5|
|The Shoulder Angle need confirmed by manufacturer and purchaser, 90℃ shoulder angle normally used in extended nozzle|
A. Plastic on-sert nozzle No.2 tube
B. Metric (V thread) open nozzle
C. Metric (V thread) sealed nozzle (membrane)
D. Extended Plastic Nozzle
E. Extended Nozzle
F. Plastic on-sert nozzle
Detailed Description of Aluminum Collapsible Hair Dye Packaging Tube:
* Material: aluminum purity>99.7%.
* Dimension: diameter from 13.5mm to 40mm, length can be customized
* Internal Lacquer: gold/silver/white colors, to keep the good nature of the cream etc. inside
* Roller Coating: white or other colors as your requests, to achieve the perfect printing effect
* Printing: six colors printing
* Bottom Latex: need or not, just depends on your requirements
* Nozzle Design: with membrane, open end, elongate nozzle, based on the customers' requirements
* Cap: various designs of caps for options
* Tube Shoulder: flat, brushed, polished, ringed or lacquered
We can deliver free samples if you need. Please feel free to contact us or email us.
It would be our great honor to send you some free samples for your quality test.
We promise "0" risk for you doing business with us, we will take 100% responsibility for our goods to avoid any lost for you. You can chose swap goods or expect a refund.
