|Place of Origin:||China|
|Model Number:||Dia 13.5mm - 40mm|
|Minimum Order Quantity:||50000 pcs|
|Packaging Details:||Packed in strong carton,suitable for long distance ocean transportation.|
|Delivery Time:||30 days|
|Payment Terms:||L/C, T/T, Western Union|
|Supply Ability:||300 millions pcs per year|
|Material:||99.7% Aluminum||Color:||Up To 6 Colors|
|Name:||Aluminum Collapsible Packaging Tubes||Nozzles:||Open, Elongated, Sealed|
|Application:||Pet Hairball Remover Packaging Tube||Artwork:||Customized|
Pet Hairball Solution Packaging Tube , Hairball Remover Tube , Cat / Dog Care Cream Tubes Packaging
Hubei Xinji Pharmaceutical Packaging Co.,Ltd located in China’s central city of Wuhan city circle, established in 1981 with nearly 40 years experience in aluminum tube manufacturing.
We are the 3rd largest manufacturer of collapsible aluminum tube industry. Our Aluminum tube is made of good quality aluminum material with advanced printing machine in a GMP workshop. These tubes are widely used for pharmaceutical ointment/cream packing, and also cosmetic packing, such as hair dying cream, hair bleaching cream, etc.
1. CAP: Colour - white / red / blue, Type - Conual Piercer, Material: HPPE.
2. Aluminum Blamks: Aluminum＞99.7% pure.
3. Internal Lacquer: Type-Expoxy-Phenolic Resin.
4. External Base Coat: Type-Enamel;Colour-White.
5. Colour Ink: Suplier-Shanghai DIC.
6. Crimp sealant brand: PPG.
7. Manufacturing Environment: The construction of 100000-ton cleaning production packing workshop.
8. Equipment: Germany PSG fully automatic production line.
9. The standard of Inspection: BS2006-86 Aluminum tube for medicine ointment.
10. Closing: Under an air pressure of 0.2Mpa, no leakage.
11. Appearance: Integrity and clean.
12. Coating: The color matches the standard,no exposure and no tiny oil droplets.
13. Color printing: Clear and entirety, the overprint is in position.
14. Flexibility and adhesion: The lacquer did not split off and no crazing.
15. Package: Wholeness and clean.
|Size & Volume|
|British Standard of Aluminum Collapsible Tube BS2006-1984|
|Sheet3 Size Standard|
|Tolerance of Diameter||
|Tolerance of Length||
|Tube Wall Thickness||Shoulder Thickness|
|Max||Min||Max||Min||Shoulder Angle Standard|
|60||0.11||0.07||0.5||0.3||90℃ or 120℃ or 126℃|
|13.5||75||60 or 70||0.11||0.07||0.5||0.3||90℃ or 120℃ or 126℃|
|16||100||80||0.12||0.08||0.65||0.35||120℃ or 126℃|
|19||110||95||0.13||0.1||0.65||0.35||120℃ or 126℃|
|22||130||95 or 115||0.14||0.1||0.65||0.35|
|25||150||95 or 115||0.14||0.1||0.7||0.4||No Standard|
|45||±0.25||200||115 or 135||0.18||0.12||0.9||0.5|
|The Shoulder Angle need confirmed by manufacturer and purchaser, 90℃ shoulder angle normally used in extended nozzle|
The quality management department is a specific department independent of others.
Equipped with professional quality inspectors and inspection facilities, it implements effective supervision towards the whole process of all activities related to the product quality though continuously self-improvement quality management system.
We adhere to “quality is out of production”, require strictly self-inspection, mutual inspection and routing inspection by operator and QC during production, to detect and solve quality problems, ensure the product safety and stability from source . Finished products gone through twice full inspection for outside tube defects, once full inspection for inside tube defects, once inside and outside casual inspection , once tightened inspection by QC .Through inspection at each process, the small probability defect of aluminum tubes reached the level of 6α.
“Make every aluminum tube trustworthy” as our quality concept to cover the whole process including products designing, developing, producing, transporting and servicing.
